Wall Thickness Gauge ECHOMETER 1076 Data
Product Description
Latest technology, modern design and an attractive price characterize the ECHOMETER 1076 Data as an innovative combination instrument for measuring wall thickness as well as sound velocity.
Thanks to the user-friendly plain-text menu, operation is straightforward. Fast quality checks in production are just as easy as measurements inside corroded containers or pipelines.
For the measurements of the ECHOMETER 1076 Data TR probes are used. The application area of the standard probe covers the most common wall thicknesses from 1.2 to 250 mm. A high-resolution probe is available for thin-walled components from 0.5 to 25 mm. Wall thicknesses up to 400 mm are measured by means of a low frequency probe.
With the built-in data memory, up to 9999 measured values with up to 999 series of measurements each can be stored, and thus also measurements can be reliably documented on site. An internal statistical evaluation is available for data related parameters. For connection to PC programs or for measurement data output a PC interface is built-in.
Key Facts
- Wall thickness measuring range (depending on the probe and the parameters microstructure, shape and surface): 0.5 to 400 mm
- Sound velocity measurement in the range 100 to 19,999 m/s
- Graphic display
- Unit switchable: mm/Inch
- Resolution switchable: 0.1 or 0.01
- Splash-proof housing according to IP54
- Dimensions: 13.1 cm x 8.1 cm x 3.2 cm, including rubber housing protection
Compared to ECHOMETER 1076 Basic:
+ Statistical evaluation
+ Data storage
+ PC interface
Versions
ECHOMETER 1076 Data (order no.: 1076.002)
The ECHOMETER 1076 Data in a rugged protective case
Further Information
Our comprehensive brochure:
Things to know and accessories:
